K4M Timing



Just want some clarification off the experienced please

is the K4M timing setup the same as the F4R,

I've got the timing tools for the F4R and done plenty of Cambelt, Dephaser, water pumps on the F4R but no experience with the K4M,

so basically can i use the same tools ?

Cheers


Mavez

ClioSport Club Member
  Clio & No Megane
I think the procedure is pretty much the same in the regard of horseshoe and locking the cams etc.. But I think the tools are slightly different, i'm sure the pin to lock the crank on the k4m is a screw in type not a slot in one. Cam locking tool is also different i think.

I think the procedure is pretty much the same in the regard of horseshoe and locking the cams etc.. But I think the tools are slightly different, i'm sure the pin to lock the crank on the k4m is a screw in type not a slot in one. Cam locking tool is also different i think.
had a suspicion they would be different, ill have a scout for the tools, cheers
