Project Nicole - 182 Track Toy Build



Been a lot of progress but haven't had much time to update this thread so ill bring it up to date in 3 or 4 chunks.
Picked up the last of the powder coating amongst which were the front wishbones that look better than new.
4-lBttzr-evUAOg-TGg4G-AalLRqFV4Cj8ivgmf4Svbs9R-F1A9t2_9XHZDXMYdzbKRvkoPqCGMrpB4GBrzzjMR9dtSMVd2DbO8Ovy99gZyM0a_T7A6r5wOkgeQwGVq7MyqYTeK8WBPCEDQzJvnISju1Pmw32M-EOHvWgNW-NbDht52E7KxQuS7XB1hRKkV199suwAHfahEoaMjHkb65dFeGnjg-qHcm_NiUy_8p2HUDxY_3ZkqjpRTh4s1xQzvZnPfjgZz6tKE0RFuJzjqe0BBuvvoohqqgBcyeBn5iSLPXsfWCaps48s0knnF0yQKupqKZDXIMwqSgeTeF9QVcZJ_JeVduSkv07RdZiP9wBDqFQim5lvjKUK6fWDNJw4OGS0SUESzjj4347VAV0tfk0UQ1wY2CUH1UGRKypLraiK0uZ99nS1MnTFWKNQJcp0-Wi19auH7s8V2XBdse381G0xZRAr_S3yp7wC6-M-r1ZrT9QpPEgPB5NpLrzUf5dP50SVcLSEL0hEL7n43NvLQ0sfXA39cCC138XOTChEhieHs0tE1TTvjiYr4WPHxGJz02hoztiljkDXJQNxGnYjANllzYNTCdVRA=w1314-h985-no


The new oil pump turned up eventually so that went on which allowed the sump to be finally buttoned up with a new sump gasket, my Renault dealer parts guy now knows me by name!!

With the engine all buttoned up Nick at PMS made me a decent offer that allowed us to convert our purchase of the AC delete and PS delete to the full lightweight pully kit so it seemed rude to refuse......
0F8uZUYKk2tTsV047vxxu9pkNosH67loScMc09P86nGe6Ko95cvHMKFsEzSzNSsbRWJ9hgj3MuT0KcXECeuTFbyA6sp1IVg8C7AWVJXeaOYJsdsKcUAjYtUfdlLNNWkfbHJ7rFzAPQf9zYPKiZLPecQebHOfvDl5l90catI9EYRW35aRNf2BUvEBEOodrtmd3GqAV_PuvLuuA6I94zoPstcZQz4PJJU9foq_OhpF2ItbMqkpyQ5jGasF1nA-dfTjtqTK2Q1jVRudv2gfe03Vfc4DEsd2tBHVWi1Epyi-Qiq2y7es03tjFhYa5RECKQ-3mrbeVE0LRB3XOJS1qDVUNEF8v0U8O2ZEWGaT6knExQeoe4SG1azM9ArYrD__4mIJpStT9YHBfwz6z4FpFnZ78DwSoeLevZbjpac1SN7F3SJxbjqCI2duYXZXsMNYKYjulCDftLTYduw2pbQJU1-cAsEi9UP0qQ_awuxvsvZwxlvwIOi0V184lgsxuqaNmnJdjfq5TwZFJMK6GroEpKGc7S6IkXjwlEM1anGJxxRp6Cp5jw2U7xxQsTg7eCRMmLebOI6KO_EaHhm-vCfM9R5UCU5sKaHsv_I=w1314-h985-no


Another afternoon in the workshop saw the engine and gearbox mated back together and the engine loom fitted back on.
8MFwQRwTMuvPA4ejRlrdmdHJmIj1bWPnDvAjrDCPy9QjTf3cXLYwzx0aCRG858B9o0ojBAFZBhkcdF7gRl0yIva_9PtxGWA92JX9zJ2BwHMcvBMC4rYlALLKBrkXVAco7gx3GSwNvb3ru-cePTIGLRh7sxQIKP1iRP4uieKi-wLt6S0oOAYEooz8_8AoD3d5KnqDdoZ1WeZMYUJga32Sl6Og4kuVv4GIh8F-Z74ACMputv5CDumHOjEyMxFTK5jHxg1hqzrLprgMpOejbpcwQSZV07N042hUahdN3cDEs1yvoSZQJQgdn3SayTLTRbzduLh_c-iOpR5HMiQp_WJnzQ-PAKLx2dW7cLaQT6Dz0ljyZeaw2dIDLZj7dp4vPlUqsjZHQsqsVP1j7qc9MO_NCNap75S2r9GQ1qxVa7vn-WexN5Uwk07eXBVLs-qz7AdbJm0lg5u38wCig6MpeArkXG_vzhU2hy5NJCpDp-LiGy2s9-CQiK6DR2k7GuBhdD4W695t4y5kqqjgHtf1Sx4lainVVXe7seXF-eEtNJ5BAbpUAFKSDeD4i2S7dBRNiYeIHTwrKvii3hf58Gnmxx2umSOenlgmCWw=w1314-h985-no



And it was only a hop skip and a jump from there to having the engine and box back in slung from the gearbox mount and engine mount. Used a new genuine gearbox mount and have supplemented the engine mount with the polybush insert which they now do in the black 90 shore material as well as the 80 shore yellow.

5OD6vO2uVq2_i98YWJwFoOl8-5xUmyVcgtyBdnVH2G3an8mw4At0SevRFeLrfJ8yYLByK7RlpsnHRgttR46Hj5dKcf9PHq0W3F4D7MS7IIhS-fkM7rkdsh3JAdwSDmy53wfOtq-U1UjajkA_7LiQtgnDwTqnE-xNjuxFIpLIt035znVPVVvgKUi4zct7BlOvb4LhIkc9uTIl_WUspe1SlGhzzoWoGildS3eN_FLTbVaft33M8FvatE6EY0WJGYm8kHbeBHhf7iCuMnOPHeXR8ObEEH38dO2hpN4WKBGMGrBsVtOfpyWcupAYEvvMdZCxl1gHEEwzHNlajzGA0SeRdepBV8vBcJXagIbHPwfH_6uM9BqkxH6y6U1qV1HHGL3xAR7Qo-XI0dTQXK8Q8jLq1IYG4zVP307ti-O8yqz0TKxXqscPkJD9ajKC_uODIy4fVM4EzniXnyQo4bumLxb7PJ13bIO_MVwSDStBiL_l6zujF3vOMzSsuOacUr84dfdIF2JwyDJ3P0-LyiXseTFLdj0RzY_ypj2GciYjdYDGN41rTqWk8uJd4fNsbgFTv2qD_cFfWjL0GEb0YGnFJM1HQwa5gBL7VlE=w1314-h985-no


More in a minute.

Poor old Nicole has led a hard life it would seem and the abortion that was the current subframe bolt setup was just awful, low grade bolts with steel nylocs tacked to hacked up washers so it was off to the parts desk again for a full set of the original front subframe bolts and the funky captive nuts that go with them.
B8rz5IuoNmE2G-5WVTGODejRjrMubLZ-Mzc0w2O1_bIvwz9HAHw3UTTgtc1wGlgKpa4YC4Zz97MfEy9gjADuCQRkTowqgYO8GASutkdd2gpknoWlA9dA5qnXeuJVyzjEx5mNaAsVRMrak4Nk-kC4IbCBzJtsbno9VkwgZvqETPfX99GtaDq-sAN8hTk7XTMInZuDiGanMl7eZ7pC1VJckc2OUckiEIRSu2kCEPONg96_t9ZwV7FsbJy01kFRwr39PQTHVb6URcAOqucD_KvTnH_441jSIBA7FApatypQxmG_u2N4SHaHgwhvvSJguxV2u-GxKLf9fHUlR8PQDUMgIeRyObXtXgu1fnHYI4KHe86QRekHRsQSwGd8WaLQg99PWGKvSp1eDJU3u8IHntbIznD7DJIVlDtyUmO_JziYmoFKdwRzcHWZw-3qsumb3GI9_svYrQ834mQK287lVw5cV9JhcDCUPAcuZZ_jrhP30Tlx3U6ieYRO3u89RXZlMKRXSURKh8v9mGDd5Td4z5P-syzi7XKGXgdeg6NyeZGgX0iFi9dzToNFmyFu7T59R-BBMfUyF7yR4NnuWTgMcr2HxlKIznYwWYM=w739-h985-no


Ukx4T7_qVitYAVDsDLAgBu8MQ8S6X7qr7t6NOCMLtkpE-8QNDLKnZI2IJE7OtmbiTcalANmMSQHp8wPpKPy6wiB9UUNELQdEjRwKxcvVJYkCYjLkl0g6ygu_dVyYHAOpauwP6OLN22ZKzCL8N7-i4A9ZS2vvz7To8VlkR203ghr4P9u3R_FbEYnRmPCTwMgb68nuuRUNPXLds7X-4pUSjf6K_j_z7l7gm1pwJjyihXrthx_JE51lxzimpbP8fR2EdhBHicIAjcysfvbhonDltlZa-Q1QQpPQhTKsvE4JFTnuXLF72tXW1iJ2zBCYu4kZIn53mZL5IXeBl-IFtuBczffo-dZgL82shLIW3XNYLkEk6zGGLEk-xLl03EK8GwfIKkpFx3-C_EBjVoL3K5bxRmbLfas7zV2CcFgqBLqkLtNbcPtbcuptyeSXyEf1TatGdkbHC30Hij4j_V-WAJIZgpvtTWzB7tiXQuMT1GLYu8M-yRCoohoKgxo-sVWxFIZzk13mbVkLM5iiePCK-ktZGeimfvDyvKjSYeP7HyeOumITbql9ttXrWUstrOdMERp22E2pklAwJ6q0k_etA2BdN3UjOM-vKQk=w739-h985-no


Got the front subframe all built up, we did have a manual rack that was sent off for refurb but good old Parcel Farce have managed to loos it so in the meanwhile we cleaned up the existing hydraulic rack, fitted new boots and drained it then fitted a loop hose.
JKyc4O4XCYeavfqk_uraJQgt02LuydYb6HTyiwywofJ7a1mKs3GDJmEcCx540KsTRCGClLIs-QJdLaczdj6lJXPlXFGBMQPli5NysDIdA7eY3MODpy8M785CbpHdQ7qrukKYInCKZgAXzFvrg8_F5YIC4ACSkd9trJb-IfIgBxN0FGgv3TBTwCZ_ngtutsz_ltVe6NU9GnZc3X1oBlJLWXDUFV-q5rqG7ZHNV6DkquUC8EOj9CJkhzWTmgONsELq6Akr_VAnxjct0ML9FY3niEb7MB6s92DjyJ0ySa5C0xzg_AGlp5rmU3BBwOVb3q1b3c-FCjEMvteHWl7g2YLnt7ximGa5qgv9UdDya02uBEUoG0FNcH4sp2h3y31VV49YPWJQPY6CpnGIAny8JRLcxImwCHe1EAqgPQe3Sb-3FoxrzMIpv7SoixcfI6WG-ZplphYV_VXOdd8aTEmSeuYKaBRHmBDGrexMsX5FmW-Jk0VD1busdsecDdLwmxRonHXUiywnCoA1o-ZdtFfzlufeLsk9-qsqFwSHP9bsmr_afzlmKfwVA7Q06jEEyLJVMk_5DkgkWehIYTo5b1s5XvY-gSCILFqU9xM=w1314-h985-no


xNjyYVLMdva_0tmm1DETTR4a87NaZMjZXHUUQwb-UnD2kiU9Jj4wx7sKeRTs_af4t1UGTKr3hEiim1fr93PPy5WAy8oq9wecerDZXOh8jz0qBtEpMurr_bmgPfW_mEOpctlFGFGt_TQy0n5F4hnP9-X2DMxys7uLYcGJIGwiV2sOwBwKKUPGpH7doJCqdYVSUF3iiAaYNJRUk5mPCyW_eqWuOpeTof3cm1kQ4H-hCkR8w7vyuHxPIWGNpWCGQ7hUoMcdQBXqDEX5ja2fohCB8fAtFQprvG-U3lVn-xM_etAB9m1Wk7PjMXbQBvemeGGgZL2EaX3mYKghK4HbKPQ90aS_8H4hoxzpu2zfGTYC0UkNA_s0LSIsnFiBdzwuNemKJ84s17R8Ap1jgme8thwB_hrOTyXmQDaqmbBBguTpZOsGv5PtI9ZKE3dqnJKmO1iFmfZ0zH82EyKs2HZ9kXRZNAX4S8HRH39pNy1X6uVdvea23cXpXp-cZY4yTQlQRSgiWPHt14J0RL7uqcJTYz2YfyXeF4eJrm4Qvlz22NOnX3M73m0a5aWuh8ypvBbRqznns2FIj1ccme45atsxhdni0wvVVfnoXM4=w1314-h985-no

As you can see the whole front end is now polybushed and again has new oe fasteners, managed to use a scrap of hose to keep the loop hose from kinking
prXCIFfE2TDCdxiBEjlVjih2opKt41vKEfGqbpyDbpGyrJpAodlsQYRJhdEhD9qbQiUB9VhLcwrkxHfEkrGSXY5-wIg2p6IqpgoLbJJcMarVQCCgkvZwgcSqDQQvsClP-Ub_c71sIHgbQf9I83lupgU6nULfWbuB4APG5gd5si2ZeL7l7lnelPQXdZZHvQB6hrfPQoenB6JEN9R2wIaq3x-QecOgwkP82ntieoftAQY-X9iLp1zH3tM-4dnAfK__x4Bo4bK6MORL_OrCE_kHXbde_GeKPNizD_dAv7c0Id1Pcy7XJ3l7ViD43z5Ugtdu7YT6ockdxM5rAa1WZEDP9fD4PymnqxVVUlSlNqfcdU_l2XkBl2W3astkaVInLmLkKbdAGVoPA0A44xhOamIyLg06-Jc3CeNjLdeImWR7ASQY6iy8en_rziQvCBAe2bP6pFjlSVOrRCd89ooq6elkLlzaRyG2PMhzdbUEtuLWKbXYRBrUX7N0raPneOYbUkrktohmKNhwbt6IlcAGRIJtmI8V1q4MXNr4LRQydY223w7VSgWdBS10ZgvnABsbwvRf_tUTcJcgv4cJfJMRLc0W3PGA129Ffds=w1314-h985-no


didn't take long from here to get the front subframe back in place
MwzYD7L-B7wb5T0mn86eSCE6EQ0JSOp_fZNVil1ntXuy9uT7lmALXK6H-PBbLIMxPzE5Anenb8JC_U1YSS4xpMkbwAxlEVsuYB-tGdoG9RpjIuiCzABWdB8_JOJEVHZQfzUQ5rw8L3STzNHG6MGKJSvZv-wr4GE1Exky7gkWjPSFUk_9tWUNRz3vwq98q1ZCzNtwnRoC9t53Xjr-oEbxgHpCXFGJK12XFaxtOavrYQ3VsZrB6fPYDgZKce_lQ1zIUmo25Tf5dgGUHz1OxttJij-7cqyesfJf5Z5oP2Roygk45lWUqdqRrBKArJ5NNTwV5FheTZ9l0s5KDoXLT9OV_IuuaR9qLSnbUxdIVBgUWD0u8sj0YuAAFB3PUAVjiouNvdAG87obB7-QAfS8FicMbWvX9aoXZCUyQiAsOPvnzCrX8IDO0Lq0qLCwvS3lyiKPYW51mudXBiAs6tZ3xI6kIfOUq8rggj6W6bie1Db8okB3Romno6ysU3PkOpN07HPFfkzkYsWau-ZfnYeEmO8qbSDop1dDoQngvbMGJ_68SXvKFMZKYL-uqOMU0DuPGWf53YgRHxTxatCf5f3Wbz3m7U8bzFzAwos=w1314-h985-no

And shortly after the parts lady delivered the new VVT valve seal for the rocker cover so the top half of the inlet went on.
dhz9uI7rcwocscL_XswbEdhlnquEkN4Mf_LD6h_WpPsi-V5H7XDQ2TMdmjO9gxOym4osJ3RTaAz26mcJzGBAH-Xt_KadAz1FRtrkuLQHidubAvsXsx6zFcWE7Y18vR4EoMNy0GEMMnz1INDTvjtXP49JxSiiXvtDnLHXPLNdgDzgCRLht1MmRD0qWDRloob9yUNeOYAlX9PWJqR1yUgz90RcyV3-lxqV4xcRjRcCeNJZi_u8JeRRHBMAV19La5ah08aIsrSV4TGcJMXxr1F6lb4ftcLiFW1glcaub-pIimr_tv-fM4pxcW9xeTJv_5qcnDugrkdDsYuXFOB1cdJquHYuqFeAECUxmlcTmktEF1YID2pDBX3d0FazY5D_uzVuMdVj6DJBrUB-0Z4sHEgq94JF0CLpggarz71br3za-JlYIvRMukjUwNAcZ0fo0rgpOvoftCmqwjwqLRWa0lzxqtRG1648GQCF1y8SFufH6JnQg6kvXi82Op0FZ-EttS-STU4GWeJPfU_JnkxHm9XOeTtaGNBpW_8mpoxhgcrYWo7RpEWz71BqlKzEONkjq9ZoubSTt4dw6d4wKaQadPvcASUB6BuVmPI=w1314-h985-no


So today we went back up spent a couple of hours checking everything, finalising the engine loom, the MAP sensor and air inlet didn't survive removal when the top inlet went away for powder coating so new pones have been fitted along with a new front Lambda sensor as when we picked it up it was showing a code for a front lambda sensor failure. Popped in the passenger side drive shaft so the gearbox would take oil and then realised that although we have tones of oil we didn't have the right gearbox oil, grrrrr there's always some thing! We did manage to get some power to it though after filling the engine with oil and the good news is that it turns over on the key and the fuel pump is definitely kicking in but for some reason it wouldn't start. At this point we had to call it a day so I'm back up to the workshop on Monday and will be trying out the CLIP I have just bought to try and diagnose why it wont spring to life, initial checks showed all the earths are good and the binnacle lights up as it should so am hopeful it wont be anything too bad. Hopefully an update will follow on Monday to let you all know she is up and running! cross your fingers for me!

TTFN
Mac & Dave

Been a lot of progress but haven't had much time to update this thread so ill bring it up to date in 3 or 4 chunks.
Picked up the last of the powder coating amongst which were the front wishbones that look better than new.
J6OfirSSH2m-PRC0Yc3hFDU_xhQPNtlh06L4wNPNziDoK_SuyUoh0aojoeGIdJrd4S8dRvW6OOri6A-tkc=w1314-h985-no.png


The new oil pump turned up eventually so that went on which allowed the sump to be finally buttoned up with a new sump gasket, my Renault dealer parts guy now knows me by name!!

With the engine all buttoned up Nick at PMS made me a decent offer that allowed us to convert our purchase of the AC delete and PS delete to the full lightweight pully kit so it seemed rude to refuse......
T_kPOeea7x0BNpBqLmStMA8X5XNXrDCl8S0ppr7dhHeEkabs4Eoic_9iwg2li4mMHptiCGiR3_sQoMAWh0=w1314-h985-no.png


Another afternoon in the workshop saw the engine and gearbox mated back together and the engine loom fitted back on.
J_K4B05-OpqMoGfyoOogrqT9s10KVbxLMP82JyTunM-Ot8kWk9b2lnf7nglDWjajfGsuG2P3T9dV9Dtr3M=w1314-h985-no.png



And it was only a hop skip and a jump from there to having the engine and box back in slung from the gearbox mount and engine mount. Used a new genuine gearbox mount and have supplemented the engine mount with the polybush insert which they now do in the black 90 shore material as well as the 80 shore yellow.
More in a minute.

Last edited by a moderator:
Poor old Nicole has led a hard life it would seem and the abortion that was the current subframe bolt setup was just awful, low grade bolts with steel nylocs tacked to hacked up washers so it was off to the parts desk again for a full set of the original front subframe bolts and the funky captive nuts that go with them.
tid-SbGrn6HxcGSXLsDv1lUCphzLROgB4HX7lX8Oa0n1MKW_bkSdKOGfOZtn_BVdDeBs3aSeD5VfUebdz_w=w739-h985-no.png


uWR6f4lWIkw3AfFVT6RruNX416w9FAqrOYXNc28jl7s0ZJjx0ILD9vkmfvbLTCzN0Y9su5lZyqg8YFloXGU=w739-h985-no.png


Got the front subframe all built up, we did have a manual rack that was sent off for refurb but good old Parcel Farce have managed to loose it so in the meanwhile we cleaned up the existing hydraulic rack, fitted new boots and drained it then fitted a loop hose.
cKGj8W8JjSr3wSJ9axxHcWkK9w4pOpdzdRlGBUamocOD4xaklwK3kv8E0ev4vRmzBAzKWAsEPdBedZaMT4=w1314-h985-no.png


As you can see the whole front end is now polybushed and again has new oe fasteners, managed to use a scrap of hose to keep the loop hose from kinking

B4sexDVfZ1S0nJ6q6e9gVutScYb_ckMm4e1crdRwAdZiX9MGY6fRjMVJmsAHzlHMywAdsK6VPIsNxqD32M=w1314-h985-no.png


Didn't take long from here to get the front subframe back in place

eIlHiMEXSngvQeZjnb_xub4GQOPv442vfCYNnjW3-UDVLGNSIHGmvUYig6p4G4KSTPVMB-nDbIs9SvCyQA=w1314-h985-no.png


And shortly after the parts lady delivered the new VVT valve seal for the rocker cover so the top half of the inlet went on.

nIWx-B6lBvz0RAMfRDrRPcgieTcCNdiONc5ovBpkxbW056bsT_B7iW5auNBQVWOy73XSt7B_IIcpPv04Jk=w1314-h985-no.png


So today we went back up spent a couple of hours checking everything, finalising the engine loom, the MAP sensor and air inlet didn't survive removal when the top inlet went away for powder coating so new pones have been fitted along with a new front Lambda sensor as when we picked it up it was showing a code for a front lambda sensor failure. Popped in the passenger side drive shaft so the gearbox would take oil and then realised that although we have tones of oil we didn't have the right gearbox oil, grrrrr there's always some thing! We did manage to get some power to it though after filling the engine with oil and the good news is that it turns over on the key and the fuel pump is definitely kicking in but for some reason it wouldn't start. At this point we had to call it a day so I'm back up to the workshop on Monday and will be trying out the CLIP I have just bought to try and diagnose why it wont spring to life, initial checks showed all the earths are good and the binnacle lights up as it should so am hopeful it wont be anything too bad. Hopefully an update will follow on Monday to let you all know she is up and running! cross your fingers for me!

TTFN
Mac & Dave

Really like what you guys have done with the clio so far. Looking forward to more pics! Im on google chrome on my phone and cant see some of the images in your posts, just shows a grey cross. Can see them in your reposts tho


Clio_fool

ClioSport Club Member
This is a great build, can't wait to see the finished car. You guys gotta bring it to csf next year!
Pics in the repost worked, others not so many. That's on tapatalk.

No updates for a while as I have been too busy working and any spare time has been spent on Nicole. finally got some free time so the updates will be coming thick and fast.
Ordered some rubber isolation mounts from these guys: https://www.vibration-mounts.co.uk/ excellent service and range and very reasonable. Used the bobbins ordered to mount the ECU on the Nearside inner wing/strut tower.
Aq-Q1eO9To6MzO_MTL5wSkKeWlB9YQq_sIXjg1TBKBdhPfFaAzfraXih3TXzaVKVptHFUKpy-1EyvKKAXPolFHhepMUUw_7JDr-OXQsfayAL1kuz5fMRaiGoWt7v2CNs1Ll_k2neNrQV2_6OjRjcNaiy-VXmRb_MqhszyuGdA0gQzHwoO7dZXDykjLiKjrrN7T9lODMOST7HfsIgfC3FbQZ72KMnhhdrKr6b1N4pBWR8Fk-u-vzwvVxVFEK6m7x_zJPShFRIT-hXPHCaO-kViQTwzG-BiZJWcCenh5ZNcCZ4B7VjImOIdy7YoHuQ-zjlkIJmNFuRwa-WMBlk7mWMo63LykVAP2vcc3cxOk0941jQVdO7Q9h3BbtEXP9Kq4tS8UppkuSS-O3-o8Vw-AU5Tuzvc3VKroXzl5BDd1HAUbggpQ2g7sO3iFc6MFbH6afTWqNsmsX0l5F6vbqzwcq7OGBma2hMq4xslZozwfc5eyiFSn79ghE-Z7B4emlpUR77LbZdNiESojqI6YjM5XfF2MNG6eTiGavXRnWuP1ADyj5w1Jfozl84mgTioU2D1iaI4e103lA6rDM2F15MnfzvHPHZIUn0ivQTiJOLn8w_B0Z8TRaC=w739-h985-no


Started on the battery relocation, one breakout box and a mega fuse mounted on the gearbox mount casting.
HVaAJddRminq2AEVjKLjTZTWM0-gwdJCeSW7v6nng87X-5utrq6nNQYjkD9Y2Mb2LW1VtkxzykfPcQZkRIoXvO-kPEOHigESnMxB0_TCXg8_3IfkMxkwaYZVS3phYXBYAnuOC4-6djuSLzEfIdDAZvsiAKkMe3v3wIDBRfzwPJqWiLSS9NgWANYMGJWHyey1AZ1fbNQ2KFpbpylWtFIF3I086fEdBd5aKzvqoNEpE49iWPgYM03oMZzlaJOiZSCkbMgzuhU2hRRxzcwCPsbwbtXv58T4YFsXLupHOoU96MFt399NG10NW4yBGHR5If1wQhT5s605nbvr6Ffs9qcUTsqyx9aH3sIa0h6kgL_Mu9DgmC_HTG06mdt2pUKQMMzuOMwdCm6znS-mkjQ4HC8fLlHQBOC5OTytBOD8qiYWia7k4A2yReQXKNb8ibP5mrFJZvwHtOb01I5o_0amJ6v8uCz9fhM4Q3YuZgoQNcrf34eG0W9xVlNzoPwyUoa-sRYEUwQlrWTEx2AE2S63vv5CQQ3o635tiSSqecIdyjgAvmzEezyURlHHl08RoGrgaV-s6t9QATKvqYu9APO31fGc_1iOX-hFAHgbIG2LpmgPUtldNOD5=w739-h985-no

Did have to cut a small hole in the side of the fuse box to re route the main fuse box power feed
X7iYY-AGppvKVucFRlwZM4SjXAbG-KUUDN8yEqXlxOf_L3v6hU0rshidRv5w0nTuFfPVWO-35a2YpBjU-dcQOWGT9sfAjmSJKXdK616xxxQ_NLyBC3LVhNiuOX0H6dwRT9xpfgvs1NMyNNxVS-oA2jWUs9jUneQOgJNccVU-hDjAzqtxJFWMTmNsLBoAgrv3SAq1pwrTgt6Q5kuq6mGqM5_dC3dWxNpW9TQQEYi5AWRao0urZbG4_qRhO4LuI4Y11La17p48DulLP6A432nW5_ZM4e9tDG29o8hhZwcmI1XtgR6RgEwr5RdEySM9vHbQVtiByCyJLT0dqAk0XI6sH11dVPH5OqyMEep1lbzag8FMgRp1VXXPjuQ4WGRf5tyw3R9-U4XbdhLmERFIYjBHvKY91GM2t4nIIVYzFGsprf12Ce-NtgWPzZ55AEfwxrrtI85mdKTU0ZnPqXCE3pZAySAgNORmSTbjHYepsfiXNFqDmgabVlCeoc6hVDkr66xAtPw853q3TqHqHowwDu8hwEpgi_VXdVHK17slWfcQGrhTs0YBALxuKvXSGjt5vnJaIgdJYg2Y_Wf-L5U5oNF3Yxx_6footflfAddV0sB7KwxiniA5=w1314-h986-no

Wiring done as far as the bulkhead connector.
MGQbLDijhw7qHZLuh-SdYDjDu5K1qdlRzNkOCRz6_msm_n5RR3DlSiJTC34HHKdZGuXqLP7Uau4YY41lbSGQkBIlRRXBlqTn8QaudEp2CzAge1hvChFoxqFHk5tp6hEF6YXAlqjHzz6VIC8opmFhDpvEjjOCA93BwRXAfhMnPE33vlK7TGVZ3F6HG0lMvcV7bgdaSGd2HTAJqf-8o_JdPEeXBxgDF8OLfenRMBKeATO3apxonOw4CXpfq3RBOfcyvcCRJaTE8yrg45K0v_gioKFCaHtPG6CWKO-IUw42HT0jouJBdfXZiwbusZ3ZDsZJyJqtMnJfIUWIxdtBy3zTbaFKjKqinnjx8uvGzF_lVgswgvXPFsqVpD8kTpRAOwZLVpEUJAl1nbXacj_4zeXOJ38KH3tBiThwV0AftCuyxNRlcsec92pZaUnq9GSQctjq4eKmLfEWPL7ffUX-MrDv_xGymt9Kddxzu2nfjH8sizrbzjhvB72S1vqX186w2x_NgnpgorFP0xsYHbI-4Va9gk_HKZnN1lLkPBukQhOgz6mUF_Uiw9hZpt57T4NEJC83-VgqNAHoAsPdDQIHMuKXOjTgx3EYpmpwnxLd4JffE4_q-JX-=w739-h985-no

Next job was to finish the front caliper refurb using the rebuild kit from Bigg Red which we also decided should include new pistons. not a difficult job but the dust seal is a bit of a pig.
Finished job.
CVkzmiTOj0mEuVk-osbmhL8_CNkZ2PwK1pg0UfbYG7y1EA4wFDxcWznSutF-g4utskzxqaz6NjVnVtFC3g2wCtL1UqrdLr9icGvGfScMr16uSr-NW9UPxQMamWfL2bL7qdVvjQALbj7wT6bYIictzCR2qjW7_7Zk94BjYyaSS2KizJNN2aRf9ujur0RgScuQPnrnKUICZBS7sAYAyh80WOgSREzO635e4vYexJ-VulCSUFNtpvjIy2eaUqZsBZ33hgcD1T5MffvIFOPII73xvW71T2Kdyl3Hu7B534zbn2C-5i7tn1411AG0TcPiv944fzne8nh_3nIuKzwroUHXaMaOlekbdGAuJOTk9aTNbtfKdFPCRaLvS50ucp4SetQ-_zEKMOttkQ2__62XTYf5pr_hc6QNH0zUH5Aw643vu5V_a_x-oSXmO_bAOatn-AMTNV-r8eGHBCt1psTr2Bigrjwj2gXWBZQPmi8ytvys_R1OCImUXQCKTsTnhv1uvS71ruRyGGGJ0wKqnIfHowbqRd83_ceT9DrswfC5FJ3y_3rxZzzKehG39TdETbVqRQPRajdG982ygIW2JmRdLMTiWidBMA27g5x0HohX-lwI07Ix64-9=w739-h985-no

UwSKlDPBRLPvpV5jtoFSD4KNgFmdD8USBAxEMPv-QYtLMDB0lYUfG0DRBU__a7NqQ_R8Na-QgMYLyu503j_dSjhhJ1O2HLFr4uN0HE806WDD6CJX3S1mfMrZq5jeEqUgqY2Dc8ak-4HPTUNe2Ytl1A6nHTe9DD-wJcF20FcezF4WFtx7PdmPAjue38Xg8xL_aS-Hrsj4R5YSJY_Vs2uGXHPhUG3l7xKSPmFfK2YGOBAEWPiEjLhxuscaJ0-j5Szoh8ZCB__Bu1JeAAWr8c3HjCuPhUJjXe-Tf20G6Z9VpYE3cLDGk88geU5PSlx2EmEyl1HcEGMhRLi6qMAKn-s-pi0XuLBAPiEcXCp-BthbL94RFwY5owJouqPxOkxQAPlJJUoyiL2-0DOqtrQCQSQf2zB5JQusBUUxvqT0Z6X3dJALnyJZzi1xGqDfBn0-FhDf5W2K8XZvaVGnMU_xLMGqGlmDIn6Jg3z47prqwKaV-0XlCcA2N9nKp7fuvl9nw4o2AHY0VBdhC-40VSHfNTuwmG9V-yAI93OfrywZ2iw9EKSoUwNVvA1r7QMw33Og64WvvCZbYPwt3u7jkAnR9Ap8z_m10rgELPSolESjskCGQC-OHDQX=w1314-h986-no

And Moving on....
Decided to use a pair of knackered old headlamp units to make some fake headlamps....yes I know.....
Cut the back out just leaving the front plastic and enough of the frame to still allow it to be bolted on.
5zWboM_hqL0IxcdVdkSQWiA9ZIf5G8R3JYLsu9PsTDNkIqIyBFATnYKU2FWam7Dv3boGpVzCkIJKIP5Z2qS=w739-h985-no.png

Coat of Plastic Primer was next
VInZPc1bQoAzVqLsWuc1RPl93vAwO2AxDVAWMm2FwoTOrgO3C24SHZlamB0lGquVBQruwLOlVDqtlyJUqAg=w739-h985-no.png

Followed by moondust silver basecoat and some lacquer
CvOA98Z5rKSfmXv0fR6eObiJuMJU9whh2UesBw4dtDdVSjTLQO63SyUzMvryFL2JvaVNp20HCr1aKoyQOUk=w739-h985-no.png


The drivers side was a bit more complex, ordered a 6 inch speaker tube
RTsmfjMAlt0QzeTrhLMedUqVMl5CwleBOJ82UarrhIG3VSm5urUf_Av9yIZvDefoUn9kQXzO6q3rJhgzJTS=w739-h985-no.png

Drew round it ont to tape then put the tape mask onto the headlamp and cut a hole, with a little fettling and l;iberal use of the heat gun the tube fitted nice and snug.
OBhEOMYWc3b3qoqA1hbcBc7bYSumzLSwMy0sq8XTHkpFTLx-j1haeW09_L1hMFEXgPygjwnw_O20NM8KTMV=w739-h985-no.png


Glued it in with 5 minute epoxy to start with then used PU adhesive from the back, its never coming out now!
Quick coat of paint and the drivers side was also done.
r4Q_HoNPwkSTIOvQt6vpaXQmMyBqbrLpKvNLWYS1kEkBHQYZHp5aJIE-vgATmQP9z0O9anPjla4n6GaL1o=w1314-h986-no.png

And the finished articles loosely in place, you can also see in this short that we painted the front support panel and decided on a new radiator, the old one was rotten and they are so cheap it would have been daft not too.
l9BwxepkrnLx6mHmHdm3XoeYBNSMw6NW8lR5R52kIRdxlt6hx4NRU5JEqbt8FAseB_MgraQyRsC-LvBSmw=w1314-h986-no.png



Ill continue with more updates tomorrow.
TTFN

Dont know whats going on with the pics as i have now tried several machines with different browsers and all have been good................. anyway ill persevere!

Next update

Managed to get a set of roll centre correction uprights of Mark (NorthLoopcup)
U05et9KteJ3XLSfrMvhNmRxPLtTxRHALBTYNxxZWfviOtvSVpuClVM5Ks6v3J3IfZ26R1El3S75JqS_-pDg=w532-h709-no.png

As you can see i had to run a tap through the wheel bolt holes to clear out the bits of powder coating.
Put the front end together with a set of BC Coilovers with the harder race springs and adjustable top mount,the calipers we refurbished ourselves and a new set of front disks off MTEC brakes who we have used for years for race and track cars with no issues. New front DS2500 front pads as well and a set of braided front lines.
NIGiPUErXYAgq07NUTsqdnIbGFcxb7e4gXmi2yMgYeuaFYGSEKTjYF85M7jLKBKt5wLouDwLBh4TPFlfZvD=w532-h709-no.png


And then fitted the fronts with a stud conversion kit
rGEeR6VI61c696sSWvPD2k64PEWyxF8HRBmgZ47doI0yw7WLg1zObP0X0C0HoYHYoOnj829gMQ4IwP0sar-=w532-h709-no.png


Used all new OE fasteners as even after putting the old ones through the electrolysis tank they were badly pitted.

then fitted up a set of Original 182 alloys we had powder coated shod with a set of Nankang NS2R's we had lying around.
HvlrKOpi39eap36OrBaFtt17b2dRktURzsCV1-6Tk9lAq2hMR2Lp_QmSGv3GbwrtkE4YYblPBEhJN23K2eC=w946-h709-no.png


Then picked up a 90 deg ali elbow of ebay to make up what i think is still referred to as the Fatty induction kit.
lpM2Y4rVFScv5IKX10jZWWLV9oGoZs-kOwfshGsMfxu-FUBt__3D_WFRTuVxvvd--ou7MvkYxWZU2l-8N1j=w532-h709-no.png


Just need to box in the filter behind the holed fake headlamp to create as much of a high pressure area as we can.

sFJapMB4z_i_bpxk6SkY0C_i05TteCOoEfSsBrwxghcQ5o4PYSZITpI6i7xTwAiEll3Dw_VdQ_KepVRu8fa=w946-h709-no.png


Possibly a further update later today.
TTFN

Managed to pick up a spare rear beam to which we welded the PMS rear beam bracing kit, well as much of it as we could bearing in mind we need to retain the spring perch fro the BC rear setup.
Had it blasted down the road so it was clean to weld to and took a coat of red oxide like a champ.
xo_VogRVO10bFNHdXkDMogtj7Bna9vujuUv4o8E4dSDte0TazbYrbYQYQhJ9bToE8h5gVTh2WP_8Bsp38A4=w946-h709-no.png


Followed by a couple of coats of Ral2004 chassis paint which was a pain as orange covers badly at the best of times, would have been a nicer job to have it powder coated but didn't want to loose momentum.
9dZy35-1rWRKGXQUj6ANZE4cEnRSM06rjnKEkSHbznJyVXUe2i5-CJlmCNXHnO6_mw7sXdtEaj7q6c6WHCk=w946-h709-no.png


Took a couple of days for the paint to harden enough to be ok to handle but then fitted the powder coated caliper mounts along with new Disc/bearing assemblies again using all new fasteners
UFA6i5j5jO7DdHiRaXKHP50f40kqfPxRYxHh8fsCsksu6qMblhP-tCly9LaQ3UbBjzQKLNO7Y3KkR-2hMji=w532-h709-no.png

another shot
YY1quizCEVhge8tehT4J6ItKYflGfAM9G7BnFALPLY2GBWylBFTMqdBSJxcHNNnXbVUJvuxkLw42Y9UEiEV=w946-h709-no.png

The white schmoo is just some spray grease i used used after as a rust prevention measure not me getting over excited !!!
New Black series rear bushes were then fitted, you can see the paint was still a bit soft at this stage as some of it ended up on the sleeve outer

o0QEZ_xlQtCgNZMXq0dWQOyw9V7LTIBVQRU61AePce5klZXHio5_v0QY70Qenhcf-edwG2fX6D-71CpjIDE=w946-h709-no.png

More Later
TTFN
