182 N/S driveshaft

STEVE.M · Nov 23, 2017

Louis' said:
That's the pic

Of the RH off side shaft.
This thread is about the N/S.
It`s in the title.

Louis · Nov 23, 2017

STEVE.M said:
Of the RH off side shaft.
This thread is about the N/S.
It`s in the title.

sorry dad

imprezaworks · Nov 23, 2017

Louis' said:
sorry grandad

Xx

LeeRS · Nov 23, 2017

STEVE.M said:
Of the RH off side shaft.
This thread is about the N/S.
It`s in the title.

Soz grandma

STEVE.M · Nov 23, 2017

Thanks boys.

LTEpic · Nov 23, 2017

Last question. What lengh are inner tie rods? I got some in garage that ill be replacing but dont want to find out theyre wrong lengh after removing them..

Sent from my SM-G930F using Tapatalk

STEVE.M · Nov 23, 2017

LTEpic said:
Last question. What lengh are inner tie rods? I got some in garage that ill be replacing but dont want to find out theyre wrong lengh after removing them..

Sent from my SM-G930F using Tapatalk

Just go for it. (Link will be dead by 2018)
https://www.renaultpartsdirect.co.uk/parts/renault-clio-range/track-rod-kit-inner-172-182/

STEVE.M · Nov 23, 2017

317mm not including the thread that screws into the rack.

oreA · Nov 23, 2017

STEVE.M said:
J&R only sell direct from eBay, Andrew Page will supply Shaftec products.

J&R seem to sell from their website too, (http://www.jandrcvjoints.co.uk/renault-clio-2.0-petrol-2003/catalogue/drive-shafts-509)unless I’ve misunderstood your post, which is quite likely 🙈:smile:. Does anyone know why there is one shaft priced at £29.95 in this link?

Soz to gatecrash this thread, but I have two driveshaft boots to replace and thought I may as well replace the shafts at this price........my car is lowered though, is the issue with this about the boot fouling on the gearbox? And will grinding a bit away solve the issue?

Thanks :up:.

LTEpic · Nov 23, 2017

STEVE.M said:
Just go for it. (Link will be dead by 2018)
https://www.renaultpartsdirect.co.uk/parts/renault-clio-range/track-rod-kit-inner-172-182/

Im gonna have to, just paranoid because ive had bad luck with clio since i bought it hah

Sent from my SM-G930F using Tapatalk

LTEpic · Nov 23, 2017

STEVE.M said:
317mm not including the thread that screws into the rack.

Thanks. Ill measure ones i got tomorrow.

Sent from my SM-G930F using Tapatalk

LeeRS · Nov 23, 2017

oreA said:
J&R seem to sell from their website too, (http://www.jandrcvjoints.co.uk/renault-clio-2.0-petrol-2003/catalogue/drive-shafts-509)unless I’ve misunderstood your post, which is quite likely 🙈:smile:. Does anyone know why there is one shaft priced at £29.95 in this link?

Soz to gatecrash this thread, but I have two driveshaft boots to replace and thought I may as well replace the shafts at this price........my car is lowered though, is the issue with this about the boot fouling on the gearbox? And will grinding a bit away solve the issue?

Thanks :up:.

I believe they all foul as a result of the boot expanding when warm.
I am not entirely sure on the reason behijd them not being suitable for lowered cars but a few people on here have ran them with no issues.
I am going to grind away the lump though jist to be sure.

imprezaworks · Nov 23, 2017

@oreA

Your car isn’t that low iirc?

oreA · Nov 23, 2017

imprezaworks said:
@oreA

Your car isn’t that low iirc?

Not particularly, Cooksports low only....
I assumed any lower than standard was relevant :smirk:.

imprezaworks · Nov 23, 2017

Be fine

STEVE.M · Nov 23, 2017

oreA said:
J&R seem to sell from their website too, (http://www.jandrcvjoints.co.uk/renault-clio-2.0-petrol-2003/catalogue/drive-shafts-509)unless I’ve misunderstood your post, which is quite likely 🙈:smile:. Does anyone know why there is one shaft priced at £29.95 in this link?

Soz to gatecrash this thread, but I have two driveshaft boots to replace and thought I may as well replace the shafts at this price........my car is lowered though, is the issue with this about the boot fouling on the gearbox? And will grinding a bit away solve the issue?

Thanks :up:.

DS21 is a RH 172 cup shaft without a support bearing.

imprezaworks · Nov 23, 2017

Steve. Did you drink a driveshaft potion one night not so long ago?

oreA · Nov 23, 2017

How many

imprezaworks said:
Be fine

:up:
How many miles have your J&Rs done, and any track ragging?

STEVE.M · Nov 23, 2017

imprezaworks said:
Steve. Did you drink a driveshaft potion one night not so long ago?

imprezaworks · Nov 23, 2017

Probably a couple of thousand tbf, worked out I’ve done about 4500 Miles I’m twelve months.

But if it helps I give it death from cold and no bend taken unless 67 degree turning angle.

imprezaworks · Nov 23, 2017

oreA · Nov 23, 2017

STEVE.M said:
DS21 is a RH 172 cup shaft without a support bearing.

Tidy, thanks! So for my non-Cup 172 I need the other two @ £50 a piece :up:. A shaft for less than £30 would've been mint though :yum::smile:!

oreA · Nov 23, 2017

imprezaworks said:
But if it helps I give it death from cold and no bend taken unless 67 degree turning angle.

Lol, and I'm a pussy on track so the J&Rs should be good :tongueclosed:.

imprezaworks · Nov 23, 2017

what could possibly go wrong :/

oreA · Nov 23, 2017

imprezaworks said:
what could possibly go wrong :/

Frankly, I don't know how my car is still going! Engine makes funny noises, gearbox whines, occasional crunch into 4th, and it spends it's life bouncing off the limiter :grinning:. The new shafts will prob hold it all together

.

STEVE.M · Nov 23, 2017

LTEpic said:
Im gonna have to, just paranoid because ive had bad luck with clio since i bought it hah

Sent from my SM-G930F using Tapatalk

How so ?
If you paid £800 for it and thought it would be like brand new, you will be disappointed.
An £800 example will require £1k spending on it immediately, and then budget £1k a year to keep it in shape.

STEVE.M · Nov 23, 2017

https://www.cliosport.net/threads/172-cup-driveshaft-sourcing.783728/page-2
been there , done this before.

LTEpic · Nov 24, 2017

STEVE.M said:
How so ?
If you paid £800 for it and thought it would be like brand new, you will be disappointed.
An £800 example will require £1k spending on it immediately, and then budget £1k a year to keep it in shape.

I paid £2500 but was so keen on owning it, I've not checked everything properly. I could of returned it but couldn't be arsed. Will just slowly fix her up how I want.

Sent from my SM-G930F using Tapatalk

STEVE.M · Nov 24, 2017

LTEpic said:
I paid £2500 but was so keen on owning it, I've not checked everything properly. I could of returned it but couldn't be arsed. Will just slowly fix her up how I want.

Sent from my SM-G930F using Tapatalk

That`s not over the top for a good example, and it will hold or even gain value if you stay on top of it.
The only other problem other than this split boot was a sticking caliper?

LTEpic · Nov 24, 2017

STEVE.M said:
That`s not over the top for a good example, and it will hold or even gain value if you stay on top of it.
The only other problem other than this split boot was a sticking caliper?

What do you mean on your second sentance?

Sent from my SM-G930F using Tapatalk

STEVE.M · Nov 24, 2017

LTEpic said:
What do you mean on your second sentance?

Sent from my SM-G930F using Tapatalk

I saw you posted about a problem with the front calipers sticking.
I assume you sorted that?
TBH, that`s not unusual if it was stood on a forecourt for a while.

LTEpic · Nov 24, 2017

STEVE.M said:
I saw you posted about a problem with the front calipers sticking.
I assume you sorted that?
TBH, that`s not unusual if it was stood on a forecourt for a while.

Ahh. Pads were seized in, replaced front pads and discs and cleaned carriers out, sorted it.
Theres a few more things I need to do, oil leak from gear selector shaft, sump gasket, poly bush ARB and steering rack bushes, poly bush dog bone.
Then cosmetical stuff: side repeaters different and one is cracked, headlight washer blanks, wheels refurb, replace piece of seat where my mate dropped superglue on, sort scuffs and scratches, fabia splitter, high level brake ligh and number plate lamp, front bumper respray, replace speedo lights to white.

I think that's it [emoji3]

Sent from my SM-G930F using Tapatalk

STEVE.M · Nov 24, 2017

LTEpic said:
Ahh. Pads were seized in, replaced front pads and discs and cleaned carriers out, sorted it.
Theres a few more things I need to do, oil leak from gear selector shaft, sump gasket, poly bush ARB and steering rack bushes, poly bush dog bone.
Then cosmetical stuff: side repeaters different and one is cracked, headlight washer blanks, wheels refurb, replace piece of seat where my mate dropped superglue on, sort scuffs and scratches, fabia splitter, high level brake ligh and number plate lamp, front bumper respray, replace speedo lights to white.

I think that's it [emoji3]

Sent from my SM-G930F using Tapatalk

So where`s the bad luck?

Gear selector weep is a standard feature, unless there is a puddle under the car every morning, it amounts to 100cc a year.
Sump gasket? Nip the bolts up before going there.

I`ve just replaced clutch, gearbox (with 089) , fitted poly bushes to rack, ARB & wishbones, & it`s worth every penny of the 10% of the hit I would have taken from bought/leased a 2016 Fiesta ST.

Craigy69k · Jul 3, 2020

Apologies for digging up again but J and R only sell one type for the 182, anyone know if these will fit a 182 cup pack, thanks?

Daz... · Jul 3, 2020

Craigy69k said:
Apologies for digging up again but J and R only sell one type for the 182, anyone know if these will fit a 182 cup pack, thanks?

182’s use the same shafts just with different width ABS rings. You will need the wider one with cup pack suspension.

Craigy69k · Jul 3, 2020

Daz... said:
182’s use the same shafts just with different width ABS rings. You will need the wider one with cup pack suspension.

Awesome, just what I was hoping for.. Thanks for the quick reply 👍
