Wiring Diagrams for DVD Unit

[CJGREEN]

Got this delivered today.

I've fitted one previously but this has a few other cables I'm not sure about.

Heres the diagrams:

iso1 by CJGREEN., on Flickr

av1 by CJGREEN., on Flickr

The ones I need to know about are:

ISO WIRE:

- 2 & 3 (is this supposed to be for the ignition?)
- 8 & 9 (they are already tided together, is this right?)
- 10 (is this for the dimmer on the dash lights?)



AV:
3 & 5 (is this where I plug my sub speaker connection too?)

Thanks,

James



[James28]

I'd imagine 2 & 3 are power feeds for the FM antenna. Not 100% though.

8 & 9 are the power connectors for the headunit.
One will need connecting to a constant 12v battery power source. Other will need connecting to a 12v source that turns on and off with ignition.

I'd guess 3 & 5 are one pair of preouts for connecting an amp/sub
and 4 & 7 are a second pair

Bit of a sham they didn't just use ISO connectors though. Would be much easier to plug and play.
